DC power supply Force-GT 24 Vdc - 20 A - 480 W DIN rail - 1-phase 230 Vac

Artikelnummer DRF-24V480W1GBA

Highly efficient compact power supply. Available with terminal connection

More information
  • Output voltage (Vdc): 24
  • Output current (A): 20
  • Input voltage (Vac): 1~230
  • Power (W): 480
  • Type: DC power supply
  • Mounting: DIN-rail
  • Sizes: 123.6mm x 56mm x 116.8mm (b x h x d)

Key features:

Built-in constant-current circuit for charging applications

Wide operating temperature range -30°C to 70°C and cold start at -40°C

Full load operating temperature up to 60°C

Long-life electrolytic capacitor

Reduced power consumption at no load

Built-in DC OK relay and LED indicator

Conformal coating on PCBs to protect against common dust and contaminants

Downloads

Brochures, manuals and technical information.
